Axial fans

FPDA

Axico Anti-Stall Vaneaxial Fan
Manually Adjustable Pitch-At-Rest

Application

The FPDA Axico Anti-Stall Fan is a vaneaxial fan with 100% stable operation. It has no stall area and no stall limit. The manually controllable fan can easily deliver the required flow or pressure in most situations by properly sizing the fan and then adjusting the blade angle of attack while the fan is energized. Model FPDA constant air volume fan propellers are equipped with mechanically-fixed, individually manually-adjustable blades that may only be re-pitched when the fan is stopped.

Sizes (propeller diameters)

  • 32 to 79 inches (815 mm to 2,010 mm)

Performance

  • Airflow to 250,000 CFM (424,800 m3/hour)
  • Static pressure to 12 inches w.g. (2,980 Pa)
